Radar solutions

Our standard products include different solutions at 24 GHz, 60 GHz and 77 GHz frequency bands. Measure directly distance, velocity, direction, angle and SNR of detected targets.

Basic 24 GHz Radars


Velocity and 1D positioning

uRAD Arduino v1.2

• FMCW radar at 24 GHz

• 1D positioning (distance only)

• Velocity, SNR, RAW data IF signal

• Arduino shield

More info

uRAD Raspberry Pi v1.2

• FMCW radar at 24 GHz

• 1D positioning (distance only)

• Velocity, SNR, RAW data IF signal

• Raspberry Pi shield

More info

uRAD USB v1.2

• FMCW radar at 24 GHz

• 1D positioning (distance only)

• Velocity, SNR, RAW data IF signal

• USB, UART

More info

High-Performance Radars


Velocity and 3D positioning

uRAD Industrial

• FMCW radar at 60 GHz

• 3D positioning, velocity and SNR

• Superior detection accuracy

• USB, serial port and Raspberry Pi adaptor

• Industrial applications

More info

uRAD Automotive

• FMCW radar at 77 GHz

• 3D positioning, velocity and SNR

• Superior azimuth angular resolution

• USB, serial port and Raspberry Pi adaptor

• Automotive applications

More info

Model uRAD Arduino uRAD Raspberry Pi uRAD USB uRAD Industrial uRAD Automotive
Frequency bandwidth 24-24.25 GHz
ISM
24-24.25 GHz
ISM
24-24.25 GHz
ISM
60-64 GHz
Industrial app.
76-81 GHz
Automotive app.
Azimuth field of view ± 15 deg ± 15 deg ± 15 deg ± 80 deg ± 60 deg
Elevation field of view ± 15 deg ± 15 deg ± 15 deg ± 80 deg ± 20 deg
Connector Arduino pins Raspberry pins USB-C / UART microUSB / UART microUSB / UART
Supply voltage 5V 5V 5V 5V 5V
Supply current 170 mA 170 mA 170 mA 340 mA 440 mA
OUTPUT DATA
Distance YES YES YES YES YES
Velocity YES YES YES YES YES
Angle NO NO NO YES YES
SNR YES YES YES YES YES
RAW data YES YES YES NO NO
Distance range 70 m (car)
40 m (person)
70 m (car)
40 m (person)
70 m (car)
40 m (person)
70 m (car)
40 m (person)
70 m (car)
40 m (person)
Accuracy range ± 0.04 m ± 0.04 m ± 0.04 m ± 0.001 m ± 0.001 m
Velocity range 75 m/s 75 m/s 75 m/s 45 m/s 45 m/s
Velocity accuracy ± 0.05 m/s ± 0.05 m/s ± 0.05 m/s ± 0.15 m/s ± 0.15 m/s
Angle accuracy - - -
More info More info More info More info More info

Custom solutions

We offer custom solutions with different antennas, connectors, communication protocols, WiFi, etc. and making use of powerful microcontrollers to meet the most demanding applications, thus covering all customer / user requirements. Contact us at contact@urad.es if you want to know more about these additional services.
